Specifications

Download brochure

Weight: 600 g
Dimensions: L 135 x W 128 x H 50 mm (excl. connectors & bracket)
Mounting: To flat surface with supplied trunnion mount
Connections: Power: 2-core captive cable, 1 m
Antenna: SO239  (VHF)
Connector GPS Antenna: TNC Connector
Data In/Out: 9-pin D-sub Connector
NMEA 2000: 5-pin 2x Data; 2x 12 V dc Power; 1x Shield
USB: USB 2.0 Type B Connector

Construction: Extruded aluminium alloy
Finish: Black paint

Power Supply: 12 V dc (9.6 - 15.6 V dc); 500 mA; 4 W nominal Peak Power: 2 A Data Output: NMEA 0183: 38,400 and 4,800 Baud

VHF Receiver: Transmitter x1;
Receiver x2 VHF
Antenna Impedance: 50 Ω
GPS Antenna Impedance: 50 Ω
Frequency Range: 156.025 – 162.025 MHz in 25 kHz steps
Channel Bandwidth: 25 kHz
Channel Steps: 25 kHz
Display: Discrete Indicator LEDs
Indicators: On, TX, RX, Status, TX Timeout, Error, TX Off
